Network In a box

Flexible deployment
All interfaces as per 3gpp
Easy to configure Maintain
SECURE
Tags: Micro eNB 20w + 20wCost effective
CNIB (Core Network In a BOX)
Integrated box with for following network Elements
MME
SGW
PGW
HSS
PCRF
NMS
Features
NAS signalling
NAS signalling security
UE Reachability in ECM-IDLE state (including control and execution of paging retransmission)
Tracking Area list management
PDN GW and Serving GW selection
MME selection for handovers with MME change
Authentication
Authorization
Bearer management functions including dedicated bearer establishment
Lawful Interception of signalling traffic
HARDWARE
Networking
IPv4
VLAN
Interface
10G SFP+
RJ-45 MGMT
Electrical
110 to 230v AC, 1 A
Mechanical
1U Network Custom Box
Compliance 3Gpp Release
Release 9
Flexible deployment
All Interfaces as per 3GPP
Easy to configure and maintain
Integrated with NMS
Features
GTP Based S5
The Local Mobility Achor Point for inter eNodeB handover
ECM-IDLE mode downlink packet buffering and initiation of network triggered service request procedure
Packet routing and forwarding;
Transport level packet marking in the uplink and the downlink, e.g. setting the DiffServ Code Point, based on the QCI of the associated EPS Bearer
Event reporting (change of RAT, etc.) to the PCRF
HARDWARE
Networking
IPv4
VPN (IPsec Tunnel mode)
VLAN
Interface
10GbE
QSFP+
RJ-45 MGMT
Electrical
110 to 230v AC, 1 A
Mechanical
1U Network Custom Box
Compliance
Release 9
Flexible deployment
All Interfaces as per 3GPP
Easy to configure and maintain
Easy to configure and maintain
Features
Per user based packet filtering (e.g. by deep packet inspection)
UE IP address allocation DHCPV4 (server and client) Functions
UL and DL Service Level gating control as defined in TS 23.203
UL and DL Service Level rate enforcement as defined in TS 23.203 (e.g. by rate policing/shaping per SDF)
DL rate enforcement based on the accumulated MBRs of the aggregate of SDFs with the same GBR QCI (e.g by rate policing /shaping)
UL and DL bearer binding as defined in TS 23.203
UL bearer binding verification as defined in TS 23.203
Accounting per UE and bearerLawful Interception of signalling traffic
Packet Screening
HARDWARE
Networking
IPv4
VPN (IPsec Tunnel mode)
VLAN
Diffserv
DHCP V4
Interface
10GbE
QSFP+
RJ-45 MGMT
Electrical
110 to 230v AC, 1 A
Mechanical
1U Network Custom Box
Compliance
Release 9
Diameter based
All Interfaces as per 3GPP
Easy to configure and maintain
Integrated with NMS
Features
Maintain and provide subscription data
Over Diameter (signaling scalability and performance)
Supporting USIM based Authentication and Encryption
User Registration management
Maintain knowledge of used PDN GW
User profile information.
Mobile Management
Service Profiling
Access Authorization, Service Authorization
User Identification, Numbering and addressing information;
User Security information: Network access control information for authentication and authorization;
User Location information at inter-system level: the HSS supports the user registration, and stores inter-system location information, etc.
HARDWARE
Networking
IPv4
VLAN
Interface
10G SFP+
RJ-45 MGMT
Electrical
110 to 230v AC, 1 A
Mechanical
1U Network Custom Box
Compliance
Release 9
Diameter based
All Interfaces as per 3GPP
Easy User Interface
Integrated with NMS
Features
Provide realtime or predefined policy rules
Provides network control regarding the service data flow detection
Policy control decision and flow based charging control functionalities
Gating Control
Authorizes the policy and charging treatment that a service data flow will receive
Efficiently and dynamically route and prioritize network traffic
Provides key inputs to revenue assurance and bandwidth management
HARDWARE
Networking
IPv4
VLAN
Interface
10G SFP+
RJ-45 MGMT
Electrical
110 to 230v AC, 1 A
Mechanical
1U Network Custom Box
Compliance
Release 9
